Procesador
Fabricante de procesador
The manufacturer that produced the processor. AMD
Socket de procesador
Mechanical component(s) that provides mechanical and electrical connections between a microprocessor and a printed circuit board (PCB). This allows the processor to be replaced without soldering. Enchufe AM4
Procesador compatible
A processor which is compatible with this device, belongs to a 'series' which is part of 'family' e.g Celeron D, Celeron G, Celeron M, or, in some cases, is the same as 'family'. AMD Ryzen™ 3, AMD Ryzen™ 5, AMD Ryzen™ 7, 3rd Generation AMD Ryzen™ 9, AMD Ryzen 9 5th Gen
Sockets de procesador soportados
The sockets (plugs) for processors that are supported (can be used) by the device. Enchufe AM4
Memoria
tipos de memoria compatibles
Types of memory which can be used with the product. DDR4-SDRAM
NĂşmero de ranuras de memoria 4
Tipo de ranuras de memoria
A memory slot, also known as a memory socket or RAM slot, is what allows computer memory (RAM) to be inserted into the computer. Depending on the motherboard, there will usually be 2 to 4 memory slots (sometimes more on high-end motherboards). The most common types of RAM are SDRAM and DDR for desktop computers and SODIMM for laptop computers, each having various types and speeds. DIMM
Canales de memoria Doble canal
ECC
ECC means Error Correction Code, and it is memory that is able to detect and correct some memory errors without user intervention.
Velocidades de reloj de memoria soportadas
Memory clock speed is the time it takes for a computer to complete basic operations. It refers to the computer's processing speed and is measured in hertz. It is however not such a reliable measure of a computer's speed as it doesn't take into account other factors like RAM and cache size. 2133, 2400, 2666, 2800, 3000, 3200, 3333, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4466, 4600, 4800 MHz
Memoria interna máxima
The maximum internal memory which is available in the product. 128 GB
Memoria sin buffer
Controladores de almacenaje
Tipos de unidades de almacenamiento admitidas
The type of storage drives the device is compatible with. HDD & SSD
Interfaces de disco de almacenamiento soportados M.2, PCI Express 3.0, PCI Express 4.0, SATA III
NĂşmero de unidades de almacenamiento compatibles
How many storage drives can be fit into the product at once. 6
Compatibilidad con RAID
The device uses RAID, which is a storage technology that combines multiple disk drive components into a logical unit for the purposes of data redundancy and performance improvement. Data is distributed across the drives in one of several ways, referred to as RAID levels, depending on the specific level of redundancy and performance required.
Niveles RAID
RAID is a storage technology that combines multiple disk drive components into a logical unit for the purposes of data redundancy and performance improvement. Data is distributed across the drives in one of several ways, referred to as RAID levels, depending on the specific level of redundancy and performance required. 0, 1, 10
Gráficos
Soporte para proceso paralelo
Parallel processing technology is the simultaneous use of more than one CPU or processor core to execute a program or multiple computational threads. Ideally, parallel processing makes programs run faster because there are more engines (CPUs or Cores) running it. In practice, it is often difficult to divide a program in such a way that separate CPUs or cores can execute different portions without interfering with each other. Most computers have just one CPU, but some models have several, and multi-core processor chips are becoming the norm. There are even computers with thousands of CPUs. No compatible
Máxima resolución
The maximum number of pixels that can be displayed in the image. It is usually quoted as width Ă— height,: for example, "1024 Ă— 768" means the width is 1024 pixels and the height is 768 pixels. 3840 x 2160 Pixeles
Interno I/O
USB 2.0, conectores
The end of a cable with a USB 2.0 connector. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), in addition to the "USB 1.x Full Speed" signaling rate of 12 Mbit/s. USB 2.0 connectors are usually colored black. 2
Conectores USB 3.2 Gen 1 (3.1 Gen 1)
This is a connector (normally attached to a cable) for USB 3.0. USB 3.0 is the second major revision of the Universal Serial Bus (USB) standard for computer connectivity. First introduced in 2008, USB 3.0 adds a new transfer mode called "SuperSpeed," (distinguishable from USB 2.0 by either the blue colour of the port or the initials SS) capable of transferring data at up to 5Gbit/s—more than ten times as fast as the 480 Mbit/s top speed of USB 2.0. 1
NĂşmero de conectores SATA III
Serial ATA (Advanced Technology Attachment) (SATA) is a computer bus interface that connects host bus adapters to mass storage devices such as hard disk drives and optical drives. SATA III (revision 3.x) interface, formally known as SATA 6Gb/s, is a third generation SATA interface running at 6.0Gb/s. The bandwidth throughput, which is supported by the interface, is up to 600MB/s. This interface is backwards compatible with SATA 3 Gb/s interface. 4
S/PDIF, conector de salida
Conector de audio en panel frontal
Conector de potencia ATX (24 pines)
NĂşmero de conectores de poder EATX 1
Conector de ventilador CPU
NĂşmero de conectores a ventilador de chasis 2
Conector de energĂa EPS (8-pin)
NĂşmero de conectores COM 1
Conector TPM
Conector eléctrico de 12 V
Conector para tiras LED RGB
Panel trasero Puertos de I/O (input/output)
Cantidad de puertos tipo A USB 3.2 Gen 1 (3.1 Gen 1) 4
Cantidad de puertos tipo A USB 3.2 Gen 2 (3.1 Gen 2) 2
Puertos Ethernet LAN (RJ-45)
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet. 1
Cantidad de puertos PS/2
The number of PS/2 connectors for keyboards and mice. Its name comes from the IBM Personal System/2. 1
Cantidad de puertos VGA (D-Sub)
Number of VGA (D-Sub) ports (connecting interfaces) in the device. The VGA (D-Sub) connector is a 15 pin connector between a computer and a monitor. It was first introduced in 1987 by IBM. 1
Panel trasero Puertos de I/O (input/output)
NĂşmero de puertos HDMI
The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards. 1
VersiĂłn HDMI 2.1
Cantidad de puertos DVI-D
This is the amount of DVI-I interfaces. Digital Visual Interface (DVI) is a video display interface developed by the Digital Display Working Group (DDWG). The digital interface is used to connect a video source to a display device, such as a computer monitor. DVI-D means DVI digital, which means it can only support digital, but not analog. 1
Salidas para auriculares
Number of sockets /ports where headphones are connected. 3
Entrada de micrĂłfono
The socket where a microphone is connected to the device.
Conector para antena WiFi-AP 1
Tipo de conector USB
The type of USB connector/port that this product has. USB tipo A
Red
Ethernet
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Tipo de interfaz ethernet Gigabit Ethernet
Controlador LAN Realtek RTL8111H
ConexiĂłn lista LAN
Wifi
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
Máximo estándar Wi-Fi
Connection of this device is done via Wi-Fi in a high standard. Wi-Fi 5 (802.11ac)
Estándares de Wi-Fi
The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office. 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Modelo de controlador WLAN Realtek RTL8821CE
Bluetooth
Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example.
VersiĂłn de Bluetooth
The type of bluetooth technology in the product e.g. Bluetooth Smart (v4.0). 5.0
CaracterĂsticas
Chipset de tarjeta madre
The chipset connects the microprocessor to the rest of the motherboard. AMD B550
Chip de sonido Realtek ALC887 / Realtek ALC897
Canales de salida de audio
An audio output channel is an electric circuit which acts as a path for a signal produced by a device. A device may have several audio output channels. 7.1 canales
Componente para
What this product is used as a part of (component for). PC
Factor de forma de la tarjeta madre
Design of the motherboard (ATX, BTX etc). Micro ATX
Familia del chipset
The category of motherboard chipset e.g. Intel, AMD. AMD
Sistemas operativos Windows soportados
Windows vesions wich can be used with the device. Windows 10 x64
Ranuras de expansiĂłn
PCI Express x1 (Gen 3.x) ranuras 2
PCI Express x16 Gen (3.x) ranuras
Places where PCI Express x16 (Gen 3.x) are placed inside and connected to the computer motherboard. 1
Ranuras PCI Express x16 (Gen 4.x) 1
NĂşmero de ranuras M.2 (M) 2
BIOS
Tipos de BIOS
The BIOS (Basic Input/Output System) initializes and tests system hardware components, and loads a bootloader or an operating system from a mass memory device. The BIOS additionally provides abstraction layer for the hardware, i.e. a consistent way for application programs and operating systems to interact with the keyboard, display, and other input/output devices. There are several types of BIOS, including the motherboard ROM BIOS, video BIOS, drive controller BIOS, network adapter BIOS, and SCSI adapter BIOS. UEFI AMI
Tamaño de memoria de BIOS 256 MB/s
Jumper Clear CMOS
Datos de logĂstica
CĂłdigo de Sistema de ArmonizaciĂłn (SA) 84733020
Peso y dimensiones
Ancho
The measurement or extent of something from side to side. 244 mm
Profundidad
The distance from the front to the back of something. 244 mm
Contenido del empaque
Cables incluidos SATA
Controladores incluidos
